Lock Washer MB24-38 Series

Specifications
Technical Data
Inquiry

■ Specifications

Lock Washer MB Series

■ Technical Data

Lock washer	Dimensions(mm)									Claws No.	Weight( 100
Lock washer	d3	M	f1	B1	f	d4	d5	r2	B2	Claws No.	Pieces/ KG)
MB24	120	115	14	2	12	138	-	1.5	6	19	10.5
MB25	125	120	14	2	12	148	-	1.5	6	19	11.8
MB26	130	125	14	2	12	149	-	1.5	6	19	11.3
MB27	135	130	14	2	14	160	-	1.5	6	19	14.4
MB28	140	135	16	2	14	160	-	1.5	8	19	14.2
MB29	145	140	16	2	14	171	-	1.5	8	19	16.8
MB30	150	145	16	2	14	171	-	1.5	8	19	15.5
MB31	155	147.5	16	2.5	16	182	-	1.5	8	19	20.9
MB32	160	154	18	2.5	16	182	-	1.5	8	19	22.2
MB33	165	157.5	18	2.5	16	193	-	1.5	8	19	24.1
MB34	170	164	18	2.5	16	193	-	1.5	8	19	24.7
MB36	180	174	20	2.5	18	203	-	1.5	8	19	26.8
MB38	190	184	20	2.5	18	214	-	1.5	8	19	27.8
